    Plc Glazed Tile Roll Forming Machine Automatic 380v

    Plc Metal Glazed Roof Tile Roll Forming Machine Machine Automatic 380v


    1. Brief introduction of Trapezoidal Roll Forming Machine


    Roof Sheet Double Layer Forming Machine,it is our company most popular products in building materials machine. For roof sheet, it include many type according to its different shape, popular type include corrugated tile roll forming machine, trapezoidal tile roll forming machine,glazed tile roll forming machine, ridge cap roll forming machine and other type profile panel roll forming machine.
    When you choose roof sheet three layers roll forming machine, you had better learn popular shape in local,also raw material is an important considering data, if do not have good supplier in local, we can assist you purchase it in China together. we are professional factory and in this area for many years, any requires please contact us at any time!

    2. Description of Trapezoidal Roll Forming Machine


    Technical parameter
    1
    Workflow
    Manual decoiling----feeding and guiding----
    roll forming----cut to length----run out table
    2
    Feeding Width
    1000mm/1200mm/1250mm
    3
    Effective width
    720mm/915mm/1000mm
    4
    Productivity
    8-10m/min
    5
    Feeding Thickness
    0.3-0.8mm
    6
    Feeding Material
    Color steel plate, galvanized sheet, aluminum coils and etc.
    9
    Hydraulic motor power
    5.5kw
    10
    Hydraulic Pressure
    18-20MPa
    11
    Voltage
    380V 3phase 50hz (or as your requirement)
    12
    Control System
    PLC Delta Inverter
    13
    Main Frame
    450mm H-Beam
    14
    Backboard Thickness
    22mm
    15
    Chain Size
    2 inch
    16
    Roller Diameter
    95mm
    17
    Roller material
    Carbon Steel 45#
    18
    Cutter material
    Cr12 , quenched
    19
    Cr-Plating Size
    0.05mm
    20
    Appearance size (About)
    12000mm*1800mm*1700mm
    21
    Weight(About)
    13 tons
    22
    Package
    nude in the container
    23
    Components
    Manual Uncoiler-------------------1 set
    Guiding Platform------------------1 set
    Coil Strip Leveler------------------1 set
    Main Machine of Roll Forming------1 set
    Electric-Motor---------------------1 set
    Cutting Device--------------------1 set
    Hydraulic Station------------------1 set
    PLC Control-----------------------1 set
    Supporter Table-------------------1 set
    24
    Minimum order quantity
    1 set
    25
    Payment terms
    T/T(30% T/T pay in advance,
    the remaining 70% pay before ship)
    26
    Delivery time
    30 working days later after receiving the deposit
    All technical parameters can be changed, according to user's need.


    3. RFQ of Trapezoidal Roll Forming Machine

    1. What is your guarantee period?
    Guaranteed against malfunctions due to manufacturing defects for 12 months from the date of loading.


    2. I do not know about the machine and do not know how to install it. Can you install the machine in my factory?
    If you need us to send engineers to your factory, you will pay for the travel expense such as visas, round tickets, hotels, and food Salary of 80 USD per day per person (from departure from our factory, until we are back to our factory). You also need to take care of his safety.


    4. What is included in the machine?
    The process for work: decoiler→feeding→roll forming→measuring length→cutting to length→product to stand
    The whole line includes 1, a manual decoiler, 2, roll forming machine, 3 product stand and 4 spare parts list.


    5. How can I start working?
    The machine is tested well and the wires are connected.


    When you get the machine in your factory, you just need to do following 3 things, and then you can start working.
    a. Put the machine on the flat level ground.
    b. Inject gear oil and hydraulic oil.
    c. Connect 3 phase electric wire.


    4. Detail photos of Trapezoidal Roll Forming Machine
