Prepainted Metal Roofing Sheet Forming Machine 380v 480v

    Buy cheap Prepainted Metal Roofing Sheet Forming Machine 380v 480v from wholesalers

    Buy cheap Prepainted Metal Roofing Sheet Forming Machine 380v 480v from wholesalers
    • Buy cheap Prepainted Metal Roofing Sheet Forming Machine 380v 480v from wholesalers

    Prepainted Metal Roofing Sheet Forming Machine 380v 480v

    Ask Lasest Price
    Brand Name : DLY
    Model Number : double layer machine
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 30sets/month
    Delivery Time : 50 days
    • Product Details
    • Company Profile

    Prepainted Metal Roofing Sheet Forming Machine 380v 480v

    380V 480V Roofing Sheet Roof Tile Making Machine With 15m Speed


    1. Brief introduction of Roof Tile Making Machine


    1.This roll forming machine can rollform metal roofing sheet. After roll formed by this roll forming machine, the surface will be very smooth and beautiful without any scratch on surface.


    2.Rollforming process:uncoiler, rollforming, forming step effect, cut to length.

    3.Fully Automatic Control System with PLC.

    4.Easy operation: Key in the length and quantity on the control panel.

    5.One year warranty.

    6.we also can do a custom roll forming machine, We can design the machine according to your specification and profile drawing.

    2. Roof Tile Making Machine specifications

    SPECIFICATIONS FOR Auto Steel Tile Roll Forming Machine
    Decoiler
    5TON manual decoiler
    Optional hydraulic decoiler
    Main forming machine
    forming steps
    14-18 stations
    rollers
    45#steel,surface chrome 0.03-0.05mm, Hard chrome mirror polishing, ensure roller smooth. Spacers must lathe inner holes, and do Chrome plating;
    shafts:
    70/75mm 45#steel,quenched
    Cutting system
    Cutter blade
    Cr12Mov, thickness 20mm
    Control system
    PLC
    Delta
    Transducer
    Delta
    Touch Screen
    Delta
    Power
    380V, 3Phase, 50Hz or as required
    Run out tables
    3m per set
    2 sets
    3. FAQ of Roof Tile Making Machine

    1. Does one machine can only produce one style panel profile?
    Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.

    2. Do you have after sales support?
    Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.

    3. How to visit your company?
    a.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour), then we can pick up you.
    b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.

    4. What can you do if the machine broken?
    Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts replace the broken parts freell,but you need pay the express cost yourself.if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.

    5. Can you be responsible for transport?
    Yes,please tell me the destination port or address.we have rich experience in transport.


    4. Machine Detals and Container Load of Roof Tile Making Machine


    Our roll forming machines have been exported to Slovenia, Bosnia and Herzegovina, Serbia, Uruguay, Russia, Canada, Australia, Nigeria, Zambia, Tanzania and etc. We were proud to receive recognized by our valued clients!


    Prepainted Metal Roofing Sheet Forming Machine 380v 480vPrepainted Metal Roofing Sheet Forming Machine 380v 480vPrepainted Metal Roofing Sheet Forming Machine 380v 480vPrepainted Metal Roofing Sheet Forming Machine 380v 480v
