3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine

    Buy cheap 3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine from wholesalers

    Buy cheap 3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine from wholesalers
    • Buy cheap 3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine from wholesalers

    3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine

    Ask Lasest Price
    Brand Name : DLY
    Model Number : door machine
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 30sets/month
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine

    Shutter Door Profiling Sheet Metal Profiling Machine With PLC Automatic


    1. Description of Sheet Metal Profiling Machine


    Rolling shutter door is commonly used for garages, shops front show windows, etc. since they are quite strong and offer proper safety to the property. The door shutter works as a curtain, providing adequate protection and safety against fire and thefts.In this way, a door is sufficiently strong and bring proper safety to glass and interiors when closed.


    2. Specifications of Sheet Metal Profiling Machine


    Suitable roll forming material
    Color steel sheet or galvanized steel sheet
    Thickness
    1.0 mm
    Frame design
    Wall-plate-frame-design/Strong-stand-frame-design
    Roll stages
    14stages
    Material of forming roller
    45# steel, CNC lathes, Hard Chrome Coated
    Shafts Diameter
    Φ75mm
    Main motor power
    7.5kw Frequency speed control
    Max. Line speed of roll former
    12m/min (Higher speed is available, depends on the specification required by the buyer)
    Hydraulic group power
    4KW
    Material of cutting blade
    Cr12, hear treatment
    Electric Standard
    380V /50Hz/3PH or as the customer's requirements
    Machine Dimensions
    7650mm×1350mm×1670mm (estimated only)
    Major Color of Machine Painted
    RAL 5015 (Blue) or as per customer’s requirements
    (2) PLC Control system
    PLC
    Siemens brand (ABB brand is available if required)
    Touch Screen
    Siemens brand (ABB brand is available if required)
    Inverter
    Schneider brand (ABB brand is available if required)
    Encoder
    Omron brand
    Description
    un-powered, 6 meters length


    3. feedback of Sheet Metal Profiling Machine


    Our metal roofing machines have been exported to Slovenia, Bosnia and Herzegovina, Serbia, Uruguay, Russia, Canada, Australia, Nigeria, Zambia, Tanzania and etc. We were proud to receive recognized by our valued clients!


    3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine


    4. details of Sheet Metal Profiling Machine


    3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine3000kg Sheet Metal Profiling Machine 4KW Shutter Door Corrugated Sheet Machine
