    PLC Downspout Pipe Roll Forming Machine 380v Downpipe Forming Machine

    Ask Lasest Price
    Brand Name : DLY
    Model Number : Rectangle pipe machine
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 30sets/month
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    PLC Downspout Pipe Roll Forming Machine 380v Downpipe Forming Machine

    Rectangle Downspout 380v 10kw Pipe Profiling Machine With PLC


    1. Description of Pipe Profiling Machine


    This Roll Forming Machine for Gutter can product various kind of arc gutters to satisfy your customer, and it can also be designed to fit for square gutters with fashion outline, the panel are very popular in our daily life, which enjoy a good market at the same time.

    You can provided the drawings what you want or real objects of sectional materials and then we will design and manufacture it for you accordingly.


    2. Specifications of Pipe Profiling Machine


    1Model No.Automatic rectangular downspout pipe roll forming machine
    2Thickness0.3-0.8mm
    3Coli materialGI
    4The bearing capacity of manual decoiler5 tons
    5shaft material45#steel
    6Out diameterCustomized
    7numbers of forming stepsCustomized
    8transmissionchain transmission
    9Forming speed10-15m/min
    10main motor power3kw
    11voltage380V50HZ Three-phase or as required
    12dimension7.5*1*1.5
    13cuttinghydraulic cutting
    14blade materialCr12 steel with quenched treated 60-62°c
    15control systemPLC(Delta)
    16length tolerance±1mm
    17spare parts

    1 easy demaged parts:conk 2pcs, fuse-link 4pcs

    2 rubber mat: 1 pcs

    3 bolt spanner: 1 pcs

    18

    The whole line including: Manual decoiler, roll forming machine, hydraulic station,

    hydraulic cutter, PLC control system, run-out table.


    3. Components of Pipe Profiling Machine


    Passive uncoil— Feeding—Roll forming—Cut to length—Output table—Elbow with pipe

    No.ItemUnitQty
    1Manual decoilerset1
    2Main roll forming machineset1
    3Main machine of compostingset1
    4PLC control boxset1
    5Supporter tableset

    1


    4. Detail Photos of Pipe Profiling Machine


    The processing and detail of each part, the assembly of the machine, all determine the quality of a machine. We strive to do a good job in every link, every process, so that the machine in the process of use can be more stable, longer service life.

    PLC Downspout Pipe Roll Forming Machine 380v Downpipe Forming MachinePLC Downspout Pipe Roll Forming Machine 380v Downpipe Forming MachinePLC Downspout Pipe Roll Forming Machine 380v Downpipe Forming MachinePLC Downspout Pipe Roll Forming Machine 380v Downpipe Forming Machine
