PLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making Equipment

    Buy cheap PLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making Equipment from wholesalers

    Buy cheap PLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making Equipment from wholesalers
    • Buy cheap PLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making Equipment from wholesalers

    PLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making Equipment

    Ask Lasest Price
    Brand Name : DLY
    Model Number : tile roofing machine
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 30sets/month
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    PLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making Equipment

    1250mm Hydraulic Cutting Steel Roofing Forming Machine With Hydraulic Cutting


    1. Description of Roofing Forming Machine


    Our high speed roll forming machine combines mechanical, electrical and hydraulic equipment into an organic whole. Features of

    this roll forming equipment include the ability to perform high speed operations with great efficiency.

    The product has been awarded 2 patents of invention and 2 patens of utility model. We can design it

    as per customers' requirements in terms of panel shape, specifications and configuration.


    2. Specifications of Roofing Forming Machine


    DecoilerLoading capacity5 Tons
    Work typePasstive
    Main roll formerRoller material45# steel with chromed treatment
    Roller shaft material45# steel with quenched treatment
    Roller shaft diameterΦ 80 mm
    Roller station17-20 roller stations
    StructureMiddle plate
    TransmissionBy double chains
    Motor power5.5 KW
    Cutting deviceCutter materialCr12
    Work speed0-15 m/ min
    Cutting typeHydraulic cutting
    Featurestable and no burr
    Cutting lengthAdjustable by PLC control system
    PLC systemPLC brandDelta
    Frequency brandDelta
    CounterOmron
    Other electric partImport brand
    Low voltage apparatusSchneider

    3. components of Roofing Forming Machine
    NOItem nameQuantity
    15 Ton manual decoiler1 set (you can change hydraulic )
    2Leveling beach with manual cutter1 set
    3Main forming machine1 set
    4PLC control system1 set
    5Hydraulic pump station1 set
    6Hydraulic shearing1 set
    7Spare parts1 set
    83m simple stacker1 set (you can choose automatic)

    4. Details of Our Roofing Forming Machine

    PLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making EquipmentPLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making EquipmentPLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making EquipmentPLC Metal Roof Panel Roll Forming Machine 80mm Roof Tin Making Equipment
