Cr12 Roofing Forming Machine 380V Glazed Tile Roll Forming Machine

    Buy cheap Cr12 Roofing Forming Machine 380V Glazed Tile Roll Forming Machine from wholesalers

    Buy cheap Cr12 Roofing Forming Machine 380V Glazed Tile Roll Forming Machine from wholesalers
    • Buy cheap Cr12 Roofing Forming Machine 380V Glazed Tile Roll Forming Machine from wholesalers

    Cr12 Roofing Forming Machine 380V Glazed Tile Roll Forming Machine

    Ask Lasest Price
    Brand Name : DLY
    Model Number : tile roofing machinery
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 30sets/month
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    Cr12 Roofing Forming Machine 380V Glazed Tile Roll Forming Machine

    Cr12 PPGI 380V Roofing Forming Machine For Metal Sheet


    1. Description of Roofing Forming Machine


    Our high speed roll forming machine combines mechanical, electrical and hydraulic equipment into an organic whole. Features of

    this roll forming equipment include the ability to perform high speed operations with great efficiency.

    The product has been awarded 2 patents of invention and 2 patens of utility model. We can design it

    as per customers' requirements in terms of panel shape, specifications and configuration.


    2. Specifications of Roofing Forming Machine


    Technical
    Specifications
    Uncoiler
    Manual Uncoiler or you can choose hydraulic decoiler
    Inner diameter
    508mm
    Outer diameter
    1250mm
    Loading weight
    5 TONs or 10 Ton
    Forming speed
    12m/min.to 50 m/min
    Forming steps
    16 stations
    Material of Shafts
    45# high-quality steel
    Diameter of Shafts
    70mm
    Material of Roller
    high quality 45#steel coated with hard chrome 0.05mm
    Thickness of Siding Plate
    25mm
    Transmission
    chains-sprockets or gearbox
    Motor Power
    15 KW
    Material of cutting blade
    Cr12 with quenched treatment 60-62
    Hydraulic Power
    4 KW
    Panasonic PLC Control system,touch screen, frequency converter
    Voltage 380V/50HZ/3phase or customize
    Details:
    1. For the gear it is important for the machine we use Chinese famous brand HRB
    2. For the leveling part, we will use two layer and handrail adjustment.
    3. For the roller we use the carefully polishing to make sure it will not damge the surface of raw material.
    The main parts of the Anti-aging IBR roof panel roll forming machine is composed by the following elements:
    · Manual Uncoiler;
    · Feeding Guider;
    · Roll forming machine;
    · Hydraulic Cutting system;
    · PLC Control System;
    · Runout Table
    For the Anti-aging heat and sound insulation wall panel IBR roofing sheet rolling machine above is about the slow speed like 25 meter per minute. We also have another options like 45 meter per minute.


    3. FAQ of Roofing Forming Machine

    • How to install the machine?

    We will give you machine manual and wiring diagram to you to help install the machine.

    The process is very easy, just need two hours even you don't have any machanical experience.

    • How about the machine working productivity?

    Machine speed is 15 m/min, if according 8 hours working everyday, each roof sheet 3 m length,

    One day can produce 240 pcs roof sheet.

    • How about the machine service life?

    If using and maintain as normal, the machine will work more than 15 years no problem.

    4. Details of Our Roofing Forming Machine

    Cr12 Roofing Forming Machine 380V Glazed Tile Roll Forming MachineCr12 Roofing Forming Machine 380V Glazed Tile Roll Forming MachineCr12 Roofing Forming Machine 380V Glazed Tile Roll Forming MachineCr12 Roofing Forming Machine 380V Glazed Tile Roll Forming Machine
