    TR40 Cr12 Corrugated Iron Rolling Machine Trapezoidal Ibr Roll Forming Equipment

    Ask Lasest Price
    Brand Name : DLY
    Model Number : TR40
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 30sets/month
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    TR40 Cr12 Corrugated Iron Rolling Machine Trapezoidal Ibr Roll Forming Equipment

    TR40 Trapezoidal Metal Roofing Sheet Roll Forming Machine With Hydraulic Cutting

    1. Description of Roofing Forming Machine

    Glazed Steel Tile Making Machinery for Colored Glazed Steel Roofing Sheet is used to make the color glazed tiles in batch by the Steel Tile Making Machinery. the finished product of Glazed Steel Tile Making Machinery For Colored Glazed Steel Roofing Sheet is widely used in the construction of various industrial plants, villages, warehouses, supermarkets, hotels, exhibition, family construction, shopping malls shutter doors and etc. It has the advantage of beautiful, classical appearance and grace taste. This machine working speed is around 4-5 meter per minutes.

    2. Specifications of Roofing Forming Machine


    FEEDINGGuide Pillar45# Steel Precision,Smoothly
    Pre cutterFully automatic Pre cutter to save your material

    ROLL MACHINE

    Frame Structure400H-beam welded and stand wall
    SidewallUse 45mm separate station box
    Screw/Bar8.8 grade / 25mm Galvanized
    Roller StationAccording to customer requirements
    Roller Shaft75mm 45# Steel Solid,Precision
    Shaft Material45# Steel Solid,Precision
    Roller Info.45# steel harden chromed plated
    TransmissionChain 1 inch
    Motor Power5.5kw
    Output SpeedAbout 10-15m/min

    CUTTING

    Frame Structure400mmCarbon Steel
    Cutting TypeHydraulic Automatic
    Cut PerformanceNo scrap,no deformation
    Cutting BladeCr12Mov,hardness 60-62℃

    HYDRAULIC

    SYSTEM

    Installationinside,easy for operation
    Pump Motor3.0KW(Lichao,Shanghai)

    COMPUTER
    SYSTEM

    Electrical Control

    Siemens

    Length ControlRotaty Encoder from Omron

    Length Tolerance

    ±1.5mm
    Touch ScreenSiemens

    Low Voltage

    Components

    Limit Switch/Contactor/Relay


    VOLTAGEAccording to customer

    3. Feathers of Roofing Forming Machine

    • We Will use the rubber roller at leveling part to protect the coil surface.
    • We will add two more gears for feeding coil smoothly.
    • For the roller, we will do the chroming for long time use and beautiful.
    • For cutting, we use 4 pillar post cutting system to make sure the cutter can use long time.
    • Use special special design of cutting system for cutting fast and the cutter can use long time.
    • Good quality hydraulic jacks.
    • Use strong thickness frame and holder.
    • We will give remoter for control machine easily.

    4. Production Flow of Roofing Forming Machine


    Manual decoiler→Feeding material into machine→Roll forming machine→Measure length→Hydraulic cutting→Finished Products

    TR40 Cr12 Corrugated Iron Rolling Machine Trapezoidal Ibr Roll Forming Equipment

    5. Details of Our Roofing Forming Machine

    TR40 Cr12 Corrugated Iron Rolling Machine Trapezoidal Ibr Roll Forming EquipmentTR40 Cr12 Corrugated Iron Rolling Machine Trapezoidal Ibr Roll Forming EquipmentTR40 Cr12 Corrugated Iron Rolling Machine Trapezoidal Ibr Roll Forming EquipmentTR40 Cr12 Corrugated Iron Rolling Machine Trapezoidal Ibr Roll Forming Equipment
