Hydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming Machine

    Buy cheap Hydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming Machine from wholesalers

    Buy cheap Hydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming Machine from wholesalers
    • Buy cheap Hydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming Machine from wholesalers

    Hydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming Machine

    Ask Lasest Price
    Brand Name : DLY
    Model Number : sinus profile
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 30sets/month
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    Hydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming Machine

    Hydraulic Cutting 380V PLC Corrugated Roofing Machine For Sinus Profile


    1. Description of Corrugated Roofing Machine

    Corrugated Roofing Machine was used for corrugate metal sheet to different profiles, then these profiles can be used as roofing, wall, fence, light steel house and etc., our roll forming machine adopt PLC automatic control system, only need one person to operate.

    this profile is very popular used for roofing, every month have this profile machine in production.

    Our advantage is we have professional design team, we take EU machine quality as our machine standard. We pay attention to every machine details and components, so the quality of our machines has been recognized by our customers and peers.


    2. Specifications of Corrugated Roofing Machine


    Article No.Item NameSpecification
    1Width of feeding materialAs ur need
    2Thickness of feeding material0.3-0.8 mm coil sheet
    3Roller station15 stations
    4Shaft Diameter80 mm
    5Productivity8-15 m/min
    6Rollers' material45# steel with 0.05mm chrome
    7Shaft material45# steel with 0.05mm chrome
    8Weight6.5 ton
    9length6.5 m
    10Voltage380V 50Hz 3phases
    11ControlPLC
    12Decoiler8 Tons
    13Motor7.5 kw
    14Driving wayChain transmission
    15Chain size1 inch
    16Cutting systemHydraulic cutter


    3. Customer Feedback of Corrugated Roofing Machine


    Our Corrugated Roofing Machine​ have been exported to Slovenia, Bosnia and Herzegovina, Serbia, Uruguay, Russia, Canada, Australia, Nigeria, Zambia, Tanzania and etc. We were proud to receive recognized by our valued clients!


    Hydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming Machine


    4.​ FAQ

    ● What is your machine warranty?

    some quick-wear parts will be container together with machine.

    if some parts damaged within one year, we will send new one to you for free, just freight up to you.


    ● Is it complicated to operate the machine?

    It is very easy, the machine is automatic, one or two persons can operate it, we provide machine use training.


    ● How many different profile roofing one machine can produce?

    One machine can produce one or two different profiles.


    5. details of Corrugated Roofing Machine


    Hydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming MachineHydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming MachineHydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming MachineHydraulic Cutting 480V Corrugated Roofing Machine 1.25m Metal Roof Forming Machine
