    0.8mm Standing Seam Roof Roll Forming Machine 50HZ Standing Seam Panel Equipment

    Automatic Metal Bead Ribs Snap Lock Metal Roofing Machine For Wall And Roof


    1. Description of Snap Lock Metal Roofing Machine

    • Manually operated E-Z cut shear
    • One steel reel
    • Two reel decoiler with friction brake
    • Automatic screw/nail hole slotter
    • All forming rollers industrial hard chrome plated
    • Length control limit switch
    • 40 feet of run-out-table
    • 10 forming stations

    2. Specifications of Snap Lock Metal Roofing Machine


    ItemParameter
    MaterialType600mm Aluminum magnesium manganese
    Thickness0.7-1.2mm
    Machine materialActive shaftNo.45 steel tempered,φ70mm diameter,HRC treading and polishing
    RollerNo.45 steel chorme plated,heat treating,polishing,CNC machining two times Roughing and finishing
    Cutting bladeCr12 quenched,polishing two times
    Power requirementType380V/3PH/50HZCustomized
    Main motorAbout 7.5Kw Simens
    HydraulicAbout 4Kw,china famous brand:shanghai li chao
    SpeedForming speedSingle 8-15mm/min,speed can be adjusted by transducer
    Manual decoilerTypeManual decoilerExpand by hand
    Max capacity5 tons
    Suitable OD600mm
    Suitable ID508mm
    Max width600mm
    Forming stand13steps roller formingL*W*H:6.2*1.4*1.3m
    Type of cuttingLength-set cutting

    Guiding pipe

    Hydraulic cutter

    Eac side one Oil cylinder

    Main body:steel panel welding

    Transmission1.0inch driveGB stander
    Control systemDelta PLC& tansducerTouch screen (delta)
    Side middle plate18mm thickness steelGB stander
    Main body Frame400 H steel,Gb stander
    Auto pre-cutting deviceFull automatic,setting any length in PLC,Hydraulic cutting system
    Film guard stand1 piece
    Machine colorMain body is sky blue color,cutting blade pillar is orange
    Machine operating programTouch scree Delta

    3. Features of Snap Lock Metal Roofing Machine
    • 6 Urethane drive rollers
    • Free-floating forming rollers mounted
    • Two sets of bead rollers included
    • Easy adjustable width of panel from 12” - 24”
    • Includes clip relief rollers
    • Easy change to different various profiles (custom design available)
    • Manual Exit end shear
    • Material width 11” to 30.5”
    • Limit switch for length control
    • Liberty wireless control For/Rev Start/Stop
    • This advanced machine comes with the any available profile up to your choice.
    • Tooling rollers are interchangeable so you can order extra tool set or few.

    4. Detail pictures of Snap Lock Metal Roofing Machine


    0.8mm Standing Seam Roof Roll Forming Machine 50HZ Standing Seam Panel Equipment0.8mm Standing Seam Roof Roll Forming Machine 50HZ Standing Seam Panel Equipment0.8mm Standing Seam Roof Roll Forming Machine 50HZ Standing Seam Panel Equipment0.8mm Standing Seam Roof Roll Forming Machine 50HZ Standing Seam Panel Equipment
