    Double Layer 0.3mm Metal Roofing Machine Plc Automatic For Sheet

    Ask Lasest Price
    Brand Name : DLY
    Model Number : double layer machine
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 30sets/month
    Delivery Time : 50 days
    • Product Details
    • Company Profile

    Double Layer 0.3mm Metal Roofing Machine Plc Automatic For Sheet

    PLC Automatic Metal Roofing Sheet Machine With 15m Speed


    1. Brief introduction of Roof Tile Making Machine


    The production size we can design the machine all as customize,customer just show us the profile drawing material thickness width,
    Different roof panel forming machines can produce different shapes of steel roof wall sheets according to the client’s profile
    drawings and requirements. The steel roof, wall sheets are new building materials with various thickness and colors. The main
    products are 840 color steel pressing tile forming machine, 860 color steel pressing tile forming machine, 900 color steel
    pressing tile forming machine, 1155 color steel pressing tile forming machine, 840/900 double-layer color steel pressing tile
    forming machine, 860/910 Double-layer color steel tile forming machine, double-layer tile forming machine, water-stopping machine,
    wall panel forming machine, roofing machine forming machine, angle-pressing tile forming machine, C-shaped steel forming machine,
    Z-shaped steel forming machine, glazed tile forming Machine, floor board forming tile machine, adjusting guardrail forming
    machine, automatic hydraulic automatic unwinding machine, leveling machine, etc.


    2. Roof Tile Making Machine specifications

    SPECIFICATIONS FOR Auto Steel Tile Roll Forming Machine
    Decoiler
    5TON manual decoiler
    Optional hydraulic decoiler
    Main forming machine
    forming steps
    14-18 stations
    rollers
    45#steel,surface chrome 0.03-0.05mm, Hard chrome mirror polishing, ensure roller smooth. Spacers must lathe inner holes, and do Chrome plating;
    shafts:
    70/75mm 45#steel,quenched
    Cutting system
    Cutter blade
    Cr12Mov, thickness 20mm
    Control system
    PLC
    Delta
    Transducer
    Delta
    Touch Screen
    Delta
    Power
    380V, 3Phase, 50Hz or as required
    Run out tables
    3m per set
    2 sets
    3. The advantage of Roof Tile Making Machine

    1.Good quality: We have a professional designer and experienced engineer team.And the raw material and accessories we use are good.

    2.Good service: we provide the technical support for whole life of our machines.

    3.Guarantee period: within one year since the date of finishing commissioning. The guarantee covers all the electric, mechanic and hydraulic parts in the line except for the easy-worn parts.

    4.Easy operation:All machine cotrolling by PLC computer controlling systerm.

    5.Elegant apperance:Protect the machine from rust and the painted colour can be customized

    6.Reasonable price:We offer the best price in our industry.


    4. Machine Detals and Container Load of Roof Tile Making Machine


    Our roll forming machines have been exported to Slovenia, Bosnia and Herzegovina, Serbia, Uruguay, Russia, Canada, Australia, Nigeria, Zambia, Tanzania and etc. We were proud to receive recognized by our valued clients!
